Stair Climber Standard SA-S
Sportiv SA-S
The Stair Climber Standard SA-S is an easy to use, portable wheelchair lift designed to attach under most manual wheelchairs. Stair Climber‘s powerful motor allows a small attendant to safely transport a larger passenger up and down stairways. Stair Climber is suitable for indoor or outdoor use in public buildings and private homes. An affordable and reliable portable access solution.
Designed as type type SA-3, but:
• Carries 150 kg capacity up to 30 levels
• Very less space needed to turn on small stair landings of 970 x 970 mm
• 80 mm shorter than SA-3
Operating
Minimum landing space
In case the width of stair is 900 mm, it may need a cut of the steering, i.e. to turn gradually with pushing machine forward and backward.
Data Sheet
Type - SA-S
capacity kg - 150
measurements L/W/H mm - 1387 x 644 x 944
weight kg - 59
power DC-E-Motor (waterproof) - 210 W / 30 min.
battery - 2 x 6 V / 20 Ah
speed upstairs - 6,1 m / min.
speed downstairs - 10,7 m / min.
stair angle max. - 35°
brakes - elektromagnetic
battery load controll - incl.
Order-No. 330.500
Accessoriesautom. charger 12 V / 2,5 A - Order-No. 333.252
Junior-platform - Order-No. 135.331
For more information, please download our latest brochure in PDF format (approx. 20MB).
